DS04 9mm德偏力矩补偿双面扣卡箍 (9mm Constant Tension Clamp with two-sided teeth)夹紧范围Size mmW2 产品货号W2 Item No.W3...
您可以通过邮箱联系我们：
| DS04 9mm德偏力矩补偿双面扣卡箍 (9mm Constant Tension Clamp with two-sided teeth) | |||
| 夹紧范围 Size mm | W2 产品货号 W2 Item No. | W3 产品货号 W3 Item No. | W4 产品货号 W4 Item No. |
| 10-16 | DS04B91016 | DS04C91016 | DS04D91016 |
| 13-18 | DS04B91318 | DS04C91318 | DS04D91318 |
| 12-22 | DS04B91222 | DS04C91222 | DS04D91222 |
| 16-27 | DS04B91627 | DS04C91627 | DS04D91627 |
| 20-32 | DS04B92032 | DS04C92032 | DS04D92032 |
| 25-40 | DS04B92540 | DS04C92540 | DS04D92540 |
| 30-45 | DS04B93045 | DS04C93045 | DS04D93045 |
| 32-50 | DS04B93250 | DS04C93250 | DS04D93250 |
| 35-55 | DS04B93555 | DS04C93555 | DS04D93555 |
| 40-60 | DS04B94060 | DS04C94060 | DS04D94060 |
| 50-70 | DS04B95070 | DS04C95070 | DS04D95070 |
| 60-80 | DS04B96080 | DS04C96080 | DS04D96080 |
| 70-90 | DS04B97090 | DS04C97090 | DS04D97090 |
| 75-95 | DS04B97595 | DS04C97595 | DS04D97595 |
| 80-100 | DS04B980100 | DS04C980100 | DS04D980100 |
| 90-110 | DS04B990110 | DS04C990110 | DS04D990110 |
| 100-120 | DS04B9100120 | DS04C9100120 | DS04D9100120 |
| 110-130 | DS04B9110130 | DS04C9110130 | DS04D9110130 |
| 材质 Material | 箍头 Housing | 钢带 Band | 螺丝 Screw | 建议安装扭力 Suggested Install Torque |
| W2 | 430ss/304ss | 430ss/304ss | zinc plated steel | 6 Nm |
| W3 | 430ss | 430ss | 430ss with zinc coating or Tin coating | |
| W4 | 304ss | 304ss | 304ss with zinc coating or Tin coating |
